- Capacity: 30kVA~10000kVA
- Voltage: 380V~35KV
- USES: Variable voltage distribution transformer
The on-load automatic capacity adjustment and voltage regulation distribution transformer has two types of rated capacity. The automatic capacity adjustment controller automatically detects and judges according to the size of the load carried by the user. Through a special on-load capacity adjustment switch, the two capacities of the transformer can be automatically switched under the state of the transformer without power failure, and the capacity of the transformer can be automatically adjusted during operation, so as to realize the automatic conversion of the two capacity operation modes of the distribution transformer.
Product Features:
1. Good Performance of Loss Reducing and Energy Saving
The load factor is elevated from 30~40% up to 70~80%, greatly increasing the transformer’s operation efficiency and reducing loss.
The capacity can be changed in time according to the electrical load. It can effectively reduce the no-load loss while improving the reliability of power supply. According to statistical data, one S11 type large and small capacity regulating transformer of 200kVA and 63kVA can save 4725kWh of electric energy per year compared with the same type of ordinary transformer.
2. Flexible Power Supply Modes, Stable Working and Simple Operation
The two capacity levels can be adjusted with no excitation according to the load status and operation units can be conveniently changed according to the status of load and voltage of the power grid, keeping the transformer operating in an economical status while remaining stable.
